    YB12C9-4A-Q Three In One IEC Inlet Filter Power Entry Module Filter

    YB12C9-4A-Q Three In One IEC Inlet Filter Power Entry Module Filter


    IEC inlet socket 3in1 10A 6A 60dB 250V power entry low pass EMI EMC noise Filter with fuse and switch


    Typical Applications of EMI filter:


    -- Portable electrical and electronic equipment


    -- Medical equipment


    -- Test and measurement equipment


    -- Small and medium-sized machines and household equipment


    Technical Specification of EMI filter:


    ItemIEC EMI Filter
    ModelYB11C9
    Transfer FunctionLow Pass
    Package TypeSurface Mount
    Nominal Center Frequency10K-30MHZ
    Insertion Loss60dB~90dB
    Input Impedance50Ω
    Rated Voltage115V/250V
    Rated Current1A~10A
    Environmental Temperature40°C
    Temperature Range25 / 100 / 21
    Operating Frequency50/60HZ
    Line to Line1450VDC
    Line to Ground2250VDC
    Maximum Leakage Current250VAC/60HZ 0.8mA Max
    MOQNegotiable
    PriceNegotiable
    Lead Time15-25 workdays

    Features of EMI filter:


    1. 2-pole rocker switch


    2. Rated currents up to 10A


    3. Single or dual-fuse holder


    Rule of Nomination of EMI filter:


    YB 11 C9 - 4A - Q ( R 5 G )

    ¦ ¦ ¦ ¦ ¦ ¦ ¦

    circuit case current connection optional


    C9: One Fuse

    C10: Two Fuses


    Tabulates of EMI filter:

    Rated Current
    @40°C

    Terminal Options*Bleeder resistor(optional)
    G
    Leakage current 250V/50HzElectrical SchematicRated Voltage(V)Operating Frequency(Hz)
    Model No.
    YB11C9-1A1AQS---<0.8mAFig.1115/250V50/60Hz
    YB11C9-2A2AQS---Fig.1
    YB11C9-3A3AQS---Fig.1
    YB11C9-4A4AQS---Fig.1
    YB11C9-6A6AQS---Fig.1
    YB11C9-8A8AQS---Fig.1
    YB11C9-10A10AQS---Fig.1
    YB11C10-1A1AQS---Fig.1
    YB11C10-2A2AQS---Fig.1
    YB11C10-3A3AQS---Fig.1
    YB11C10-4A4AQS---Fig.1
    YB11C10-6A6AQS---Fig.1
    YB11C10-8A8AQS---Fig.1
    YB11C10-10A10AQS---Fig.1

    Medical type Tabulates of EMI filter:

    Model No.Rated Current
    @40°C
    Terminal OptionsBleeder resistor(optional (MΩ)Medical equipment
    5

    G
    Leakage current 250V/50HzElectrical SchematicRated Voltage(V)Operating Frequency(Hz)
    YB11C9-1A-x(R5)1AQS-15-<5μAFig.2115/250V50/60Hz
    YB11C9-2A-x(R5)2AQS-15-Fig.2
    YB11C9-3A-x(R5)3AQS-15-Fig.2
    YB11C9-4A-x(R5)4AQS-15-Fig.2
    YB11C9-6A-x(R5)6AQS-15-Fig.2
    YB11C9-8A-x(R5)8AQS-15-Fig.2
    YB11C9-10A-x(R5)10AQS-15-Fig.2
    YB11C10-1A-x(R5)1AQS-15-Fig.2
    YB11C10-2A-x(R5)2AQS-15-Fig.2
    YB11C10-3A-x(R5)3AQS-15-Fig.2
    YB11C10-4A-x(R5)4AQS-15-Fig.2
    YB11C10-6A-x(R5)6AQS-15-Fig.2
    YB11C10-8A-x(R5)8AQS-15-Fig.2
    YB11C10-10A-x(R5)10AQS-15-Fig.2

    *Q: Fast-on 6.35x0.8mm S: solder 4.0x0.8mm W: UL1015 18awg


    An electrical schematic of EMI filter:

    Fig.1

    Standard type

    Fig.2

    R5 type



    Mechanical Dimension(Unit: mm)


    CaseABCDEFGHIJK
    C9/C105848295040531111173.36.35*0.8
    Tolerances
    公差
    ±1±1±1±1±0.15±1±0.5±0.5±0.5±1±0.15

    Insertion loss table(In 50ohm system according to IEC/CISPR No.17)


    Common mode -------- differential mode

    1A 3A

    6A 8A

    10A


    The factory pictures

    Single Phase Filter:
    cUL:20190321-E471748
    TUV:B0899310001Rev.01
    CQC:19001226449
    CE:SZAIS180620005-01
    ROHS:MMCRHRWM60371744
    Three Phase Filter:
    cUL:20190325-E502442
    ENEC:ENEC-02580
    CE:SZAIS180620005-01
    ROHS:MMCRHRWM60371744

    Sample

    Sample Fee: Negotiate

    Sample Time: 3~5 days


    Payment

    ---Payment terms: Western Union, D/P, T/T,L/C

    ---Please remember to leave the correct contact information for delivery.


    Packaging

    Power Line Filter: CTN/96pcs

    N/G W.: 9.696/10.83KG

    Measures:0.565*0.285*0.225m


    FAQ:
    Q: What are the main products of your company?
    A: IEC inlet socket EMI filter, single-phase filter, Three-phase RFI filter, house appliance noise filter, Medical equipment filter, inver/converter EMC filter, etc.

    Q: How is the quality of your product?
    A: All our products have pass UL, TUV, CE, ROHS, ISO9001 approval. which ensures the quality of the product.

    Q: What are services available for pre-batch orders?
    A: Free samples and EMC technical rectification services are supplied before-sale

    Q: What are services available after-sale?
    A: Free replacement within three-month, free maintenance within six-year, life-long maintenance.

    Q: What facilities do you have?
    A: We have our own laboratory and production base to establish large-scale production.

    Q: What the delivery time for 1000pcs of EMI FILTER?
    A: Normally 15-20 days, but we can coordinate for a better delivery time if it is urgent.
