110v 220v Single Phase RFI Filter For Cooling Conditioner Equipment
110v 220v 1-20A EMI EMC Filters for Heating and cooling conditioner
equipment
| Item | Power line EMI Filter |
| Model | YB12D3-20A-S(R) |
| Transfer Function | Low Pass |
| Package Type | Surface Mount |
| Nominal Center Frequency | 10K-30MHZ |
| Insertion Loss | 60~90dB |
| Input Impedance | 50Ω |
| Rated Voltage | 115V/250V |
| Rated Current | 1~30A |
| Environmental Temperature | 40°C |
| Temperature Range | -25℃~+85℃ |
| Operating Frequency | 50/60HZ |
| Line to Line | 1450VDC |
| Line to Ground | 2250VDC |
| Maximum Leakage Current | 0.4mA/115V,60HZ; 0.8mA/250V, 50HZ |
| MOQ | Negotiated |
| Price | Negotiated |
| Lead Time | 15~20 workdays |
Features:
-- The compact size can be applied to various situations.
-- Two YB12 filters are also available as two-stage filters(YB35)
in a noisy environment
-- There are a variety of parts and combinations to meet different
customer's EMC tests.
-- Customized products according to customer's requirements.
Typical Applications:
-- Electrical and electronic equipment
-- Medical equipment
-- Datacom equipment
-- Office automation equipment
Rule of Nomination:
YB 12 D3 - 20A - S ( R 5 )
¦ ¦ ¦ ¦ ¦ ¦
circuit case current connection optional
S::Screw
Q: fast on
W: wire-lead
*Q: Fast-on 6.35x0.8mm
S: Screw lug
W: UL1015 18awg
Electrical schematic:
Mechanical Dimension(Unit: mm)
Insertion loss table(In 50ohm system according to IEC/CISPR No.17)
Common mode ---------------- differential mode
10A 20A
Sample
Sample Fee: Negotiate
Sample Time: 3~5 days
Payment
---Payment terms: Western Union, D/P, T/T, L/C
---Please remember to leave the correct contact information for
delivery.
Packaging
Power Line Filter: CTN/80pcs
N/G W.: 14/15.3KG
Measures:0.565*0.285*0.205m
Shipment
---Shipping terms: DHL, UPS, FEDEX, TNT, EMS
---Port is Shenzhen or as requests.
