Special Type Socket EMI Filter With Fuse And Switch 1A~10A Power Entry Module Filter

IEC inlet filters YB-C series

Features:

-- Rated currents up to 10A

-- Single fuse holder

-- 2-pole rocker switch

-- General-purpose application

-- Approvals:

Rule of Nomination:

YB 11 C7 - 3A - Q ( R5 )

¦ ¦ ¦ ¦ ¦

circuit case current connection optional

Electrical schematic:

Standard type

R5 type

Tabulates:

Rated Current @40°C

Terminal Options*

Bleeder resistor (optional)

Ground (Optional)

Leakage current 250V/50Hz

Electrical Schematic

Rated Voltage(V)

Operating Frequency(Hz)

Model No.

YB11C7-1A

1A

Q

S

-

-

-

<0.8mA

Fig.1

115/250V

50/60Hz

YB11C7-2A

2A

Q

S

-

-

-

Fig.1

YB11C7-3A

3A

Q

S

-

-

-

Fig.1

YB11C7-4A

4A

Q

S

-

-

-

Fig.1

YB11C7-6A

6A

Q

S

-

-

-

Fig.1

YB11C7-8A

8A

Q

S

-

-

-

Fig.1

YB11C7-10A

10A

Q

S

-

-

-

Fig.1

YB11C7-1A

1A

Q

S

-

-

-

Fig.1

YB11C7-2A

2A

Q

S

-

-

-

Fig.1

YB11C7-3A

3A

Q

S

-

-

-

Fig.1

YB11C7-4A

4A

Q

S

-

-

-

Fig.1

YB11C7-6A

6A

Q

S

-

-

-

Fig.1

YB11C7-8A

8A

Q

S

-

-

-

Fig.1

YB11C7-10A

10A

Q

S

-

-

-

Fig.1

Medical Type Tabulates:

Rated Current @40°C

Terminal Options

Bleeder resistor (optional)R(MΩ)

Medical equipment (optional)5

Ground (optional)

Leakage current 250V/50Hz

Electrical Schematic

Rated Voltage(V)

Operating Frequency(Hz)

Model No.

YB11C7-1A-x(R5)

1A

Q

S

-

1

5

-

<5μA

Fig.2

115/250V

50/60Hz

YB11C7-2A-x(R5)

2A

Q

S

-

1

5

-

Fig.2

YB11C7-3A-x(R5)

3A

Q

S

-

1

5

-

Fig.2

YB11C7-4A-x(R5)

4A

Q

S

-

1

5

-

Fig.2

YB11C7-6A-x(R5)

6A

Q

S

-

1

5

-

Fig.2

YB11C7-8A-x(R5)

8A

Q

S

-

1

5

-

Fig.2

YB11C7-10A-x(R5)

10A

Q

S

-

1

5

-

Fig.2

*Q: Fast-on 6.35x0.8mm S: solder 4.0x0.8mm W: UL1015 18awg

Mechanical Dimension(Unit: mm)

C Case

YB11C7-10A-Q Product Pictures:

Insertion loss table(In 50ohm system according to IEC/CISPR No.17):

differential mode

1A 3A 6A

8A 10A

Shipment:
