High Performance Three Phase Filter 6A 10A 380V EMI/RFI Filter For Inverter

Ask Lasest Price
Brand Name :	YBX
Model Number :	YX83G1-6A-S
Certification :	cUL, ENEC, CE, ROHS, ISO
Price :	Negotiable
Supply Ability :	2000pcs per month
Delivery Time :	15-25 days

Add to Cart

Product Details
Company Profile

High Performance Three Phase Filter 6A 10A 380V EMI/RFI Filter For Inverter

Multiband AttenuationThree Phase Filter 6A 10A 380V 30MHz EMI/RFI Filter For Inverter

Technical Specification:

Item	Three Phase Filter
Model	YX83G1-6A-S
Transfer Function	Low Pass
Package Type	Surface Mount
Nominal Center Frequency	150K-30MHZ
Insertion Loss	60~90dB
Input Impedance	50Ω
Rated Voltage	380V/440V
Rated Current	6A-100A
Environmental Temperature	40°C
Temperature Range	25 / 085 / 21
Operating Frequency	50/60HZ
Line to Line	1450VDC
Line to Ground	2250VDC or 2000VAC
Maximum Leakage Current	250VAC/60HZ 1.4mA Max. 440VAC/60HZ 2.5mA Max
MOQ	5pcs
Price	USD4.8~88/Meter
Lead Time	3~15 weekday for Three Phase EMI Filter

Features:

-- Protection against interference of voltage

-- YX83 filters provide a broadband common and differential-mode attenuation performance, it still can be available when the interference is larger

-- Customized products according to customer's requirements.

Typical Applications:

-- For photovoltaic systems and industrial applications

-- Three-phase motor drives

-- UPS/SMPS

-- Industrial automation equipment

Filter Selection Table:

Part No.	Case	Rated Currents (A)	Output Connections
YX83G1-10A	G1	10	Fast-on terminal
YX83G1-20A	G1	20	Fast-on terminal
YX83G1-30A	G1	30	M4/M6/M8 Screw
YX83G1-40A	G1	40	M4/M6/M8 Screw
YX83G1-50A	G1	50	Terminal block

*Q: Fast-on 6.35x0.8mm S: Screw lug T: Terminal block

Tabulates:

Model No.

Rated Current
@40°C

Terminal Options*

Leakage current 440V/50Hz

Electrical Schematic

Rated Voltage(V)

Operating Frequency(Hz)

YX83G1-1A

<1.0mA

Fig.1

250/440V

50/60Hz

YX83G1-3A

Fig.1

YX83G1-6A

Fig.1

YX83G2-10A

10A

Fig.1

YX83G2-15A

15A

Fig.1

YX83G2-20A

20A

Fig.1

YX83G3-10A

10A

<2.0mA

Fig.1

YX83G3-20A

20A

Fig.1

YX83G3-30A

30A

<5.0mA

Fig.1

YX83G5-30A

30A

Fig.1

YX83G5-50A

50A

Fig.1

YX83G5-60A

60A

<7.0mA

Fig.1

YX83G4-100A

100A

Fig.1

YX83G4-150A

150A

Fig.1

YX83G6-200A

200A

<10.0mA

Fig.1

Electrical Schematic:

Mechanical Dimension(Unit: mm)

Case	A	B	C	D	E	F	G	H	I	J	K	L

G1	72	65	39	75	85	35	22		45	M4	M4/M6

G2	98	80	40	95	105	50	20	4.5*6.5	50	M4	M4/M6

G3	120	100	50	115	130	50	28	4*6	60	M4	M4/M6

G4	200	127	80	150	170	62	49.5	6*9	117	M6/M8	M8/M10

G5	150	105	60	120	135	55	35	4*6	90	M6	M8

G6	260	170	100	196	220	85	65	8*12	172	M8	M10

Tolerances	±1	±1	±1	±0.15	±1	±0.5	±0.5	±0.15	±0.15		±0.15

Insertion loss table(In 50ohm system according IEC/CISPR No.17)

High Performance Three Phase Filter 6A 10A 380V EMI/RFI Filter For Inverter

Working Environment:

Our company:

1. Customized: We have a professional R&D team; our aims is we won't let customers spend any extra money.

2. Listed company: National high-tech enterprises, brand assurance, reliable quality, and we have the relevant product certifications.

3. Rectification test: We cooperate with top scientific research laboratories to provide free EMC rectification technical support, samples; and free conduction test.

4. Scale production: Automation technology, scale production, great price,excellent, service,fast delivery! Free replacement within three months, free maintenance within six years, life-long maintenance!
